The CM12M30M12QU3, featuring the Sony IMX577 image sensor, is a high-speed 12MP USB 3.0 camera module optimized for industrial imaging. This integration ensures the high resolution and robust functionality required for advanced microscopy and digital imaging systems.


Technical Information：
Product ID
  CM12M30M12QU3
Sensor  IMX577
Image Size  1/2.3 inch
Image Pixels & Resolution  12M / 4000(H) x 3000(V)
Image Formats  MJPEG / YUY2(YUYV)
Frame Rate  4000x3000 MJPEG@18fps
 3840x2160 MJPEG@30fps
 4000x3000 YUY2@8fps
 3840x2160 YUY2@15fps
Max S/N Ratio  40dB
Dynamic Range  83dB
Min. illumination  0.1 lux
Sensitivity  700mV/lux-sec@550nm
Shutter Type  Electronic rolling shutter /
 Frame exposure
Connecting Port
  USB3.0 High Speed
Plug & Play  UVC(USB Video Class) support
Operating Temperature  -20° ~ 60°C
Operating Voltage  DC5V
Operating Current  480mA
PCBA Dimensions  38x38mm
Operating System Request  Win8/Win10/Win11
 MAC-OSX EI caption 10.11.4
 Linux / Android with UVC
12M USB3.0 Camera Module – CM12M30M12QU3

產品特點

12M(4000x3000) Image Sensor IMX577
USB3.0 Hight Speed
Dimensions: Square 38x38mm
M12 S-mount Lens Type(Fixed Focus)
- Standard: FL3.24mm
- Option: FL2.7 / FL3.9 / FL4.3 / FL8
- Autofocus: FOV(D)100
UVC support, Plug & Play for Windows and Linux

Datasheet

Download

基於 0 筆評價 - 如果您對本商品有任何問題，請在此留下您的意見和建議！
NT$5,120
10 件(含)以上NT$4,352
50 件(含)以上NT$3,584
200 件(含)以上NT$2,880
  • 交期預估: 可供貨, 7~21 天
  • 產品型號: CM12M30M12QU3

選項及配件：

加入購物車
立即購買 聯絡我們
商品收藏 商品比較
Note:

可配合客戶規格需求,提供客製化服務。

更多資訊請 聯繫我們。
